Traxxas TRX-4 Sport 1/10 Scale Trail Rock Crawler W/XL-5 ESC & TQi 2.4GHz Radio (Red)

Product Description

Traxxas TRX-4 Sport 1/10 Scale Trail Rock Crawler w/XL-5 ESC & TQi 2.4GHz Radio (Red)

The TRX-4 Sport combines the unbeatable ground clearance and driving dynamics of Traxxas portal axles, sticky Canyon^® Trail tires, and a lightweight pickup truck body for a leaner, performance-focused new TRX-4. The Sport’s unique bumpers, wheels, and body were designed for increased performance in technical sections. Whether it’s a fun trail run or a hardcore technical crawl, the TRX-4 Sport’s capability and purpose-built approach takes your outdoor adventures to a new level.

Features:

• Chassis:
• Heavy-Duty Steel Frame Rails
• Adjustable Wheelbase
• Molded Wire Retainers
• Dual Battery Tray
• Floor Pans
• Aluminum Scale Shocks
• Heavy-Duty Steel Links
• Precision Hex Hardware
• Driveline:
• Portal Axles
• Torque Twist Eliminated
• Locked Differentials
• Steel Gear Transmission
• Hardened Steel U-Joints
• Twin Friction Plate Slipper Clutch
• Sealed Ball Bearings
• Geometry:
• Raised Center Driveshafts and Suspension Links
• High Steering and Drag Links
• 45-Degree Steering Angle
• Extreme Approach Angles
• High Ground Clearance
• Front Motor Design
• Electronics:
• XL-5 HV ESC
• Titan 21T 550 Motor
• Waterproof Metal Gear Servo
• TQ™ 2-Channel Radio System

Specifications:
Length: 21.93 inches (557mm)
Front Track: 9.78 inches (249mm)
Rear Track: 9.78 inches (249mm)
Ground Clearance: 3.14 inches (80mm)
Weight: 5.79lb (2.63kg)
Height: 9.47 inches (241mm)
Wheelbase: 12.28 inches (312mm)
Approach Angle: 58.82°
Departure Angle: 45.83°
Breakover Angle: 58.93°
Front Shock Length: 3.54 inches (90mm)
Rear Shock Length: 3.54 inches (90mm)
Front Wheels: 1.9 x 1.02 inches (49 x 26mm)
Rear Wheels: 1.9 x 1.02 inches (49 x 26mm)
Front Tires: 4.64 x 1.89 inches (118 x 48mm)
Rear Tires: 4.64 x 1.89 inches (118 x 48mm)
Hex Size: 12mm
Speed Control: XL-5 HV
Motor (electric): 21T Reverse Rotation
Transmission: Single Speed
Gear Pitch: 32P
Differential Type: Spool (no differential)
Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers
Brake Type: Electronic “Hill Hold”
Drive System: Shaft Driven 4WD
Steering: Chassis Mounted Servo
Servo: 2075X Metal Gear
Transmitter: TQ™ 2.4GHz 2-Channel Transmitter
Receiver: 6519
Skill Level: 2
Battery Tray: 158.75 L x 47 W x 23/26mm H
