Traxxas Summit 1/10 Scale 4WD Extreme Terrain Monster Truck (Orange)

Product Description

Traxxas Summit 1/10 Scale 4WD Extreme Terrain Monster Truck

Versatile All-Terrain Performance with High-Low Transmission and Remote Locking Differentials!

When the trail gets tough, you can count on Summit to pull through. The Traxxas Summit offers versatility, durability, and off-road capability greater than any other 4WD monster truck. Our engineers packed Summit with high-tech innovations like our transmitter-operated high/low transmission and remote-locking front and rear differentials. Summit generates massive torque from the giant 775 Titan^® motor while the rugged ExoCage™ keeps Summit safe on the trail. These are just some of the weapons in Summit’s off-road arsenal. When you drive a Summit, no stream is too big, no trail is too tough, and no hill is out of reach.

Features:

• Transmitter-operated remote locking differentials
• Transmitter-operated high-low transmission
• Titan^® 775 brushed motor w/ 5mm shaft, 10 Turn, 16.8v
• TQi 2.4GHz 4-channel transmitter and micro receiver w/ Waterproof Receiver Box
• Waterproof 16.8v EVX-2 Electronic Speed Control
• Dual Digital High Torque Waterproof Steering Servos (TRA2075)
• 17mm splined aluminum hex hubs
• Industry’s first dual-CV telescoping half shafts
• Geode™ rims and Canyon AT™ tires
• ExoCage™ body
• 10-LED light system
• Specially tuned long-travel suspension

Specs:

• Length: ­ 22.17 inches (563 mm)
• Front Track: ­ 18.48 inches (470 mm)
• Rear Track: ­ 18.58 inches (472 mm)
• Center Ground Clearance: ­ 4.76 inches (121 mm)
• Weight: ­ 175.66 ounces (4.98 kg) (w/o batteries)
• Height (overall): ­ 12.6 inches (320 mm)
• Wheelbase: ­ 14.84 inches (377 mm)
• Front Shock Length: ­ 87 mm
• Rear Shock Length: ­ 87 mm
• Front Tires (pre-glued): ­ Canyon AT™ (7.1″ x 3.8″)
• Rear Tires (pre-glued): ­ Canyon AT™ (7.1″ x 3.8″)
• Front Wheels: ­ 3.8″ Geode™ (chrome)
• Rear Wheels: ­ 3.8″ Geode™ (chrome)
• Speed Control Type: ­ EVX-2 with Low Voltage Detection, forward/reverse/brake
• Motor (electric): ­ Titan® 775, High-Torque fan cooled (10-turn)
• Transmission: ­ High-low two-speed
• Overall Drive Ratio: ­ Stock, out-of-box: 25.34 (high gear), 70.18 (low gear)
• Differential Type: ­ Bevel gear, sealed, limited slip
• Gear Pitch: ­ 32-pitch
• Chassis Structure/Material: ­ Molded composite Nylon tub
• Brake Type: ­ Electronic
• Drive System: ­ Shaft-driven 4WD
• Steering: ­ Bellcrank
• Radio System: ­ TQi™ 2.4GHz (4-channel)
• Skill Level: 2

Needed to Complete:

• (2) 7 cell Flat 3000mAh NiMH Batteries with Traxxas iD Connector (TRA2923X) OR
• (2) 2 cell 7.4v 5800mAh LiPo Batteries with Traxxas iD Connector (TRA2843X) OR
• (2) 2 cell 7.4v 7600mAh LiPo Batteries with Traxxas iD Connector (TRA2869X)
• Suitable Charger (TRA2972)
• (4) AA Batteries for Transmitter

• Parts

  • Parts for the Traxxas Summit

• Resources

  • Manual for the Traxxas Summit
  • Chassis Assembly Exploded View for the Traxxas Summit
  • Driveshafts Assembly Exploded View for the Traxxas Summit
  • Front Assembly Exploded View for the Traxxas Summit
  • Rear Assembly Exploded View for the Traxxas Summit
  • Shift Assembly Exploded View for the Traxxas Summit
  • Transmission Assembly Exploded View for the Traxxas Summit

Other Details

Vehicle models vary. We DO NOT guarantee this will fit the vehicle specified in this listing! Verify that this item is appropriate for your vehicle. Consult your manual or vehicle manufacturer. Verify vehicle fit-ment before purchase. Any and all warranty claims will be handled through the manufacturer directly.
