Name: Spektrum S150 AC/DC 50W Smart Charger
SKU: SPMXC1070
Availability: InStock

Product Description

Spektrum S150 AC/DC 50W Smart Charger

With the compact S150 AC Mini Smart Charger, modelers of all experience levels can enjoy the charging advantages of innovative Spektrum™ Smart technology. This 50 watt charger brings advanced Smart charging capabilities and features to an affordable platform that features an easy-to-use, one-button interface.

When used with Spektrum Smart batteries with an IC3™ or IC5™ connector, the S150 uploads charging data from each battery’s integrated memory chip. That pack-specific data helps you evaluate battery health and makes charging a snap — because the S150 can read and make the correct chemistry setting automatically. The S150 AC Mini Smart Charger is compatible with LiPo, Lilon, LiHV, and NiMH battery types.

Smart Technology — More connected for more confidence and control

Spektrum™ Smart Technology is about offering a higher connection to your hobby. It’s an RC ecosystem that puts you in complete control while making vital components of your model easier to use than ever before. Smart technology ensures that all of your model’s electronics work together seamlessly for the greatest efficiency and performance. It keeps you aware of every component’s status, boosts your confidence in its capabilities, and makes your entire system more responsive and simple to use.

Spektrum radios with Smart features can download firmware updates instantly using Wi-Fi and can swap setups with compatible radios via Bluetooth. Spektrum Smart LiPo batteries have a built-in microchip that records and communicates your charging preferences automatically to Smart chargers — just connect your pack and press “Start.” Smart IC™ series connectors include an innovative data wire that transfers information easily between Smart components with a single connection. Finally, Smart ESCs not only deliver power but also eliminate the hassles from running telemetry. The days of installing and connecting multiple wires, sensors, modules and links are over.

Features:

Recognizes unique Smart battery data for safe, easy charging
Can also be used to charge batteries without Smart technology
50 watts of charging power, up to 5 amps of charge current
Compact, easily portable design
One-button interface and simple to understand charging indicator
Adaptable for AC power input (includes AC to 20V DC power supply)
Quiet internal cooling fan maintains a safe, efficient operating temperature
Supports charging LiPo, Lilon, LiHV, and NiMH battery types
Accepts future Smart technology updates

Specifications:
Battery Balance Connector: JST-XH
Battery Temperature Monitoring: Yes, Temperature Sensor Included
Battery Type: 1-4S LiPo, LiFe, LiHv/ 1-12C NiMH, NiCd
Circuit Breaker: Yes
Cooling Method: Fan
Display: 2.4″ 320×320 IPS LCD
Height: 1.12″ (28.5mm)
Input Voltage: 100-240V AC
Integrated Balancing: Y-Internal Balancer & External Adapter
Length: 2.5″ (65mm)
Low Input Voltage Protection: Yes
Material: Plastic Case
Maximum Charge Rate: 17.4V, 5A, 50W
Model Memory: Smart ID
Output Connector: IC3 (Compatible with EC3)
Over Current Protection: Yes
PC Connectivity: Yes-USB, External Adapter Required
PC Required: No
Peak Detection: Yes
Reverse Polarity Protection: Yes
Safety Timer: Yes
Selectable Charge Rate: Yes-Incremental (0.1A Increments)
Short Circuit Protection: Yes
Software Updates: Yes, Via USB Port
Thermal Protection: Yes
Type: AC Powered Smart Battery Charger
Weight: 2.2oz (63g)
Width: 1.9″ (49mm)

Includes:

(1) Spektrum™ S150 AC Mini Smart Charger
(1) AC to 20V DC 3 Amp Power Supply
(1) Product Manual

Needed to Complete:
Nothing! The Spektrum™ S150 is usable with your Smart batteries, as well as regular, compatible batteries, right out of the box.

Resources
- Spektrum S150 AC Smart Charger Instruction Manual
